1 Door Laminate Base Cabinet
Product SKU
Description
- Includes an adjustable shelf
- Left and right hinge door available
- Pricing is INCLUDED in model
- Cost estimate updates dynamically with changes made to the model
1 Door Plastic Laminate Base Cabinet
Our one-door base cabinet is part of Southwest Solutions’ modular casework line; a flexible and durable alternative to built-in millwork. This is a highly customizable family, and all of our casework is backed with a Limited Lifetime Warranty. The cabinet is finished on all four sides and uses 2mm PVC edge banding for a durable, long-term solution. Use simple parameters to choose various handles, door types, toe kicks, and more.
The Southwest Solutions Group casework line is designed to be highly flexible and adaptable with every Revit model built to reflect its real world counterpart. Once loaded, each model has a variety of parameters which allow you to easily manipulate and customize various aspects of the casework design without ever needing to load a type catalog ever again.
Such features include:
- Quickly Manipulate Sizes
- Toe Kick Options
- Door Styles
- Handle Types
- Lock Options
- Angled Top Options
- Material Options
In addition, each model comes with a high level of information built in, including a worst-case budget price that dynamically updates as you manipulate the model within Revit. This allows the designer and client to quickly understand where the money is being spent. Also, within each model type, there are links to more detailed information should you need it. Having this level of flexibility combined with a high level of information is truly what BIM is meant to be.
| Parameter | Value |
|---|---|
| Standard Widths | 12", 15", 18", 21", 23", 24" |
| Minimum Width | 1 |
| Maximum Width | 2 |
| Standard Depths | 24", 30" |
| Minimum Depth | 1.33333 |
| Maximum Depth | 2.5 |
| Standard Heights | 29", 33", 35", 37", 41" |
| Minimum Height | 1.5 |
| Maximum Height | 3.41666 |
| Cabinet Design Series (CDS) | 101 |
| Manufacturer | Southwest Solutions Group_HAM |
| Lead Time | 4-6 Weeks |
| Construction Type | Frameless cabinet construction w/ flush overlay fronts |
| Keynote | 12 32 16 |
| Assembly Code | E2020 |
| Author | KBruxvoort |
| Toll Free Number | 1-800-803-1083 |
| Property | Value |
|---|---|
| Equalis | No |
| Omnia | No |
| Sourcewell | No |
| Systec | Yes |
| Vizient | Yes |
| Includes Pricing | Yes |
| ADA Compliant | Yes |
| Has MEP Connectors | No |
| Primary Material | Laminate |
| BIMobject Category | Furniture: Shelving & Storage |
| IFC | Furniture |
| Omniclass | 23-21 19 11 13 |
