Filing Rail Cantilevered Rack

Store hanging files or other objects with this cantilevered rail
Wall-mounted or interchangeable rack-mounted options available

Family

Revit 2019 (0.52 MB)

Revit 2021 (0.52 MB)

Revit 2022 (0.52 MB)

Revit 2023 (0.52 MB)

Revit 2024 (0.52 MB)

Revit 2025 (0.52 MB)

Revit 2026 (0.52 MB)

Revit 2027 (0.52 MB)

(0.23 MB)

Questions

Need some help? Send us a message if you have any sales or model related questions.

Cantilever Filing Rack

Use this cantilevered rail to store hanging files or virtually any object that fits between the rails. This product is frequently used outside the office to store basketballs, volleyballs, or soccer balls.

To use this family, simply insert it into your project and use the align tool to connect it to a wall or existing shelving system. The rail spacing can be adjusted by entering a length into OFFSET_Back Rail.

Parameter	Value
Standard Widths	30", 42"
Minimum Width	1' 0" (12")
Maximum Width	4' 0" (48")
Standard Depths	15"
Minimum Depth	1' 0" (12")
Maximum Depth	2' 0" (24")
Standard Heights	3", 4"
Minimum Height	0' 3" (3")
Maximum Height	0' 4" (4")
Manufacturer	Southwest Solutions Group_OBL
Lead Time	Ships in 5 business days
Model	UF
MasterFormat	10 56 29.26 – Cantilever Storage Racks
UniFormat	E2010 – Fixed Furnishings

Property	Value
Includes Pricing	No
ADA Compliant	No
Has MEP Connectors	No
IFC	Furniture
OmniClass	23 40 70 14 57 – Office Equipment and Furnishings
Omnia	No
Sourcewell	No
Equalis	Yes
Vizient	Yes
Systec	Yes

View all

Model	Width	Depth	Height	Weight
SSG-UF1212	1' 0" (12")	1' 0" (12")	0' 4" (4")	8
SSG-UF1214	1' 0" (12")	1' 2" (14")	0' 4" (4")	9
SSG-UF1216	1' 0" (12")	1' 4" (16")	0' 4" (4")	10
SSG-UF1218	1' 0" (12")	1' 6" (18")	0' 4" (4")	11
SSG-UF1220	1' 0" (12")	1' 8" (20")	0' 4" (4")	12
SSG-UF1222	1' 0" (12")	1' 10" (22")	0' 4" (4")	13
SSG-UF1224	1' 0" (12")	2' 0" (24")	0' 4" (4")	14
SSG-UF2412	2' 0" (24")	1' 0" (12")	0' 4" (4")	10
SSG-UF2414	2' 0" (24")	1' 2" (14")	0' 4" (4")	11
SSG-UF2416	2' 0" (24")	1' 4" (16")	0' 4" (4")	12
SSG-UF2418	2' 0" (24")	1' 6" (18")	0' 4" (4")	13
SSG-UF2420	2' 0" (24")	1' 8" (20")	0' 4" (4")	14
SSG-UF2422	2' 0" (24")	1' 10" (22")	0' 4" (4")	15
SSG-UF2424	2' 0" (24")	2' 0" (24")	0' 4" (4")	16
SSG-UF3612	3' 0" (36")	1' 0" (12")	0' 4" (4")	12
SSG-UF3614	3' 0" (36")	1' 2" (14")	0' 4" (4")	13
SSG-UF3616	3' 0" (36")	1' 4" (16")	0' 4" (4")	14
SSG-UF3618	3' 0" (36")	1' 6" (18")	0' 4" (4")	15
SSG-UF3620	3' 0" (36")	1' 8" (20")	0' 4" (4")	16
SSG-UF3622	3' 0" (36")	1' 10" (22")	0' 4" (4")	17
SSG-UF3624	3' 0" (36")	2' 0" (24")	0' 4" (4")	18
SSG-UF4812	4' 0" (48")	1' 0" (12")	0' 4" (4")	14
SSG-UF4814	4' 0" (48")	1' 2" (14")	0' 4" (4")	15
SSG-UF4816	4' 0" (48")	1' 4" (16")	0' 4" (4")	16
SSG-UF4818	4' 0" (48")	1' 6" (18")	0' 4" (4")	17
SSG-UF4820	4' 0" (48")	1' 8" (20")	0' 4" (4")	18
SSG-UF4822	4' 0" (48")	1' 10" (22")	0' 4" (4")	19
SSG-UF4824	4' 0" (48")	2' 0" (24")	0' 4" (4")	20
