Product SKU
Description
- Ideal for use in any educational, or professional lab setting
- Choose between 2, 3, or 4 outlets
- 90° and 180° options available for 2 outlet configuration
- Easily mounts to countertop with 3/8" IPS female inlet
Revit 2020 (0.53 MB)
Revit 2021 (0.53 MB)
Revit 2022 (0.53 MB)
Revit 2023 (0.53 MB)
Revit 2024 (0.53 MB)
Revit 2025 (0.53 MB)
Revit 2026 (0.53 MB)
(0.15 MB)
Deck Mounted Gas Valve
This versatile gas valve family is able to add or subtract gas outlets based on your needs. Select a type to choose between 1 outlet, 2 outputs at 90° and 180°, 3, or even 4 outlet units. This family is face-based and can be applied directly to your desired counter top. Integral, straight, serrated hose attachment is fully modeled for render-ready projects.
| Parameter | Value |
|---|---|
| Standard Widths | 5 1/8", 8 3/8" |
| Minimum Width | 0' 5 1/8" (5 1/8") |
| Maximum Width | 0' 8 3/8" (8 3/8") |
| Standard Depths | 2", 5 1/8", 8 3/8" |
| Minimum Depth | 0' 2" (2") |
| Maximum Depth | 0' 8 3/8" (8 3/8") |
| Standard Heights | 3 1/2" |
| Minimum Height | 0' 3 1/2" (3 1/2") |
| Maximum Height | 0' 3 1/2" (3 1/2") |
| Manufacturer | Southwest Solutions Group_PRI |
| Lead Time | Contact SSG for more information |
| Model | L4200 |
| Keynote | 22 63 00 |
| Assembly Code | D2060.30 |
| Author | KBruxvoort |
| Toll Free Number | 1-800-803-1083 |
| Property | Value |
|---|---|
| Equalis | No |
| Omnia | No |
| Sourcewell | No |
| Systec | No |
| Vizient | No |
| Includes Pricing | Yes |
| ADA Compliant | No |
| Has MEP Connectors | Yes |
| Primary Material | Chrome |
| BIMobject Category | Plumbing: Valves |
| IFC | Valve |
| Omniclass | 23.65.00.00 |
