Box-2 Unit-6 Tier 4 Post Shelving Revit model group
Box-2 Unit-6 Tier 4 Post Shelving Revit model group
Updated Jul 27, 2021

Box-2 Unit-6 Tier 4 Post Shelving

Product SKU

SKU: SSG-4P-116-BOB

Downloads

Get Fetch to load families straight into Revit →
Model group
Pricing

Description

  • 6 Tiers High
  • Great for file storage
  • Flexible components for adaptable storage
  • Shelf system

Questions about this product?

This 84 × 16 × 76 in. box-storage shelving run combines two 6-tier 4-post assemblies for business storage areas that need a 7-foot-wide layout within a 16-inch depth. The powder-coated steel shelf system provides six tiers for box and file storage while keeping the overall run at 76 inches high. Shelves adjust independently in 1-1/2-inch increments, so teams can revise shelf spacing as stored materials change. Formed steel uprights use keyhole slots, and shelf supports interlock with steel shoulder rivets, allowing assembly without nuts, bolts, or clips. Listed accessories include file dividers, center stops, reference shelves, back stops, backs, bin dividers, bin fronts, laminate end panels, and end-panel mounting brackets.

The 4-Post line is designed to be highly flexible and adaptable with every Revit model built to reflect its real world counterparts as closely as possible. Use the prebuilt shelving family to visualize your storage solutions or use the shared sub-component families to build your own custom solution right down to the last shelf.

Our 4-Post shelving incorporates both “L” & “T” shaped uprights allowing for a variety of shelving configurations. All shelf units are assembled without the use of nuts, bolts, or clips and are available for both single entry (wall unit) and double entry (back to back storage) allowing for maximum filing/storage capacity with minimal floor intrusion. Shelves are available slotted to accept adjustable file dividers. All shelf units are designed for expansion and are available as mobile-ready for easy conversion. Our 4-Post units are ready to assemble with no special tools required. Available depths make it an ideal choice for letter, legal, binder, and book storage applications.

Specifications
Dimensions
Width84"
Depth16"
Height76"
Product
Number of Columns2
Number of Levels6
Primary MaterialPowder coated steel
Type of Storage SizeBox
Classification
IFCFurniture
OmniClass23-21 11 11 11
Revit family
Includes PricingYes
ADA CompliantNo
Has MEP ConnectorsNo
Configurable options
  • Base option
  • Divider option
  • Dividers per shelf
  • Openings
  • Back panel
  • Doors
  • Open upright
