High Density Steel Bike Rack
Product SKU
Description
- Price included in model
- Powder coat finish options, rubber-coated arms
- Wall or Floor-mounted with optional wheel stop bar
- Floor-mounted units must be anchored to the floor
- Double-sided option available to maximize capacity
Powder coated steel high density bike rack
The high density unit is modular to fit in nearly any space. With design enhancements, the double-sided model parks more than double the capacity of a standard bike rack. Options include: wall-mount, floor-mount, and double-sided.
The modular bike storage systems store bikes safely and securely for temporary or long-term parking. Each product can be expanded upon to suit your space or storage capacity goals.
Features include:
- Dedicated, secure storage for bikes
- Modular design fits nearly any space
- Galvanized, stainless, or powder-coated steel finish options
In addition, each model comes with a high level of information built in, including links to more detailed information should you need it. Having this level of flexibility combined with a high level of information is truly what BIM is meant to be.
| Parameter | Value |
|---|---|
| Standard Widths | 38", 54", 70", 86", 102", 118" |
| Minimum Width | 3.16667 |
| Standard Depths | 31 11/16", 57 3/8" |
| Minimum Depth | 2.6406 |
| Maximum Depth | 4.7813 |
| Standard Heights | 81" |
| Minimum Height | 6.75 |
| Maximum Height | 6.75 |
| Manufacturer | Southwest Solutions Group_DER |
| Lead Time | Contact SSG for info |
| Keynote | 12 93 13 |
| Assembly Code | E2010 |
| Author | ssmartin |
| Toll Free Number | 1-800-803-1083 |
| Property | Value |
|---|---|
| Includes Sustainability | Yes |
| Includes Pricing | Yes |
| ADA Compliant | No |
| Has MEP Connectors | No |
| Primary Material | Powder coated steel |
| BIMobject Category | Furniture: Shelving & Storage |
| IFC | Furniture |
| Omniclass | 23-11 29 11 11 |
