· Updated Aug 19, 20213 Tier - 12"W x 24"D Column Laminate Day Lockers
Product SKU
SKU: SSG-3T-122472
Description
- Kit is designed for multiple user locker areas
- Locks are cable-free and battery powered
- Kit includes 18 total lockers
Revit 2018 (3.17 MB)
Revit 2019 (3.17 MB)
Revit 2020 (3.17 MB)
Revit 2021 (3.17 MB)
Revit 2022 (3.17 MB)
Revit 2023 (3.17 MB)
Revit 2024 (3.17 MB)
Revit 2025 (3.17 MB)
Revit 2026 (3.17 MB)
Revit 2027 (3.17 MB)
(0.05 MB)
(0.43 MB)
(8.14 MB)
3 Tier - 12"W x 24"D Column Laminate Day Lockers is a 72" W x 24" D x 72" H, 18-locker kit for shared day-use storage in high-traffic facilities. Its six multi-door laminate locker components create a three-tier arrangement across a 6-foot-wide bank, providing a specified 24-inch depth for university, airport, gym, and office locker areas. Each locker uses a keyless, cable-free, battery-powered lock with an LED to identify available lockers, so users can find open storage without keys or transponders. The locks are unaffected by power outages and do not require external programming devices; a master code is possible. The metal lock housing has a matte chrome front finish and a stated lifespan of up to 100,000 closures. Download the free Revit family.
Each smart day use locker kit was created for high traffic applications like universities, airports, gyms, or offices. Each lock comes with a brightly shining LED which identifies available lockers. Locks are keyless and cable-free so they are unaffected by power outages.
Design
- Other lock type options can be chosen with a potential upcharge. Including Radial combination locks and RFID locks
- Angled top is optional
- Number of Doors, Width, Depth, and Height can be chosen to fill exact needs
| Parameter | Value |
|---|---|
| ENTER Lock Type Number | 2 |
| ENTER Number of Lockers | 3 |
| Width | 1' 0" (12") |
| Cabinet Depth | 2' 0" (24") |
| Height | 6' 0" (72") |
| ADD Angled Top | 0 |
| ADD Integrated Toe Kick | 1 |
| ADD Left End Panel | 0 |
| ADD Right End Panel | 0 |
| Left Hinge | 0 |
| Property | Value |
|---|---|
| Includes Pricing | Yes |
| ADA Compliant | No |
| Has MEP Connectors | No |
| Width | 6' 0" (72") |
| Depth | 2' 0" (24") |
| Height | 6' 0" (72") |
| Number of Columns | 6 |
| Day Locker Tiers | 3 |
| Primary Material | Laminate |
| IFC | Furniture |
| OmniClass | 23-19 13 13 |
