· Updated Oct 7, 2024TA50 Gear Welded Wire Locker
Product SKU
Description
- Structural integrity with heavy-gauge steel
- Meets U.S. Military requirements for securing personell equipment and gear
- Mesh allows for quick visual inspection and ventilation
- Easy to assemble
Revit 2020 (0.77 MB)
Revit 2021 (0.77 MB)
Revit 2022 (0.77 MB)
Revit 2023 (0.77 MB)
Revit 2024 (0.77 MB)
Revit 2025 (0.77 MB)
Revit 2026 (0.77 MB)
Revit 2027 (0.77 MB)
(0.02 MB)
(2.78 MB)
(0.31 MB)
(6.84 MB)
(9.45 MB)
(0.25 MB)
Gear Storage Locker
Our free Revit models are packaged with detailed and specific information without the extra requirements needed of a massive file size. These lockers are modular in creation and application, and can be reconfigured as needed. Easy to plan, easy to install, easy to relocate. Available in single, double, and triple-tier units, and can be combined.
| Parameter | Value |
|---|---|
| Standard Widths | 36", 42" |
| Minimum Width | 3' 0" (36") |
| Maximum Width | 3' 6" (42") |
| Standard Depths | 24" |
| Minimum Depth | 2' 0" (24") |
| Maximum Depth | 2' 0" (24") |
| Standard Heights | 78" |
| Minimum Height | 6' 6" (78") |
| Maximum Height | 6' 6" (78") |
| Manufacturer | Southwest Solutions Group_FOL |
| Lead Time | 1-2 Weeks |
| Model | FG-TA50 |
| MasterFormat | 10 51 43 – Wire Mesh Storage Lockers |
| UniFormat | E2010 – Fixed Furnishings |
| Property | Value |
|---|---|
| Includes Pricing | Yes |
| ADA Compliant | No |
| Has MEP Connectors | No |
| Primary Material | Powder coated steel |
| IFC | Furniture |
| OmniClass | 23-29 15 15 21 |
