Universal Workstation Stainless Steel Table

Downloads

RFARevit family
PDFINSTALL SSG table SST180 KB
PDFCut sheet120 KB

Get Fetch to load families straight into Revit →

Family

Pricing

ADA

Universal stainless steel table
Available with lower shelf or tube supports
Optional casters available
Marine edge and variety of backsplash heights

Questions about this product?

Stainless Steel Table

This universal stainless steel table can be used in virtually any setting and can be configured to fit your unique storage needs. The workstation tables can range from 24” to 144” wide and 24” to 36” deep on 6” increments. The table height is adjustable using threaded feet on each leg. Shelf or tube supports available. Backsplash is optional at 1 1/2” or 4 1/2”. A marine edge can also be added for a modest charge.

Specifications
Dimensions
Width	24", 30", 36", 48", 60", 72", 84", 96", 108", 120", 132", 144
Depth	24", 30", 36"
Height	35" to 36"
Product
Manufacturer	Southwest Solutions Group_EAG
Model	SMS-88-T
Primary Material	Stainless steel
Classification
IFC	Furniture
Revit family
Includes Pricing	Yes
ADA Compliant	Yes
Has MEP Connectors	No

Model	Width	Depth	Height	Weight
SMS-88-T2424B	2' 0" (24")	2' 0" (24")	3' 0 1/8" (36 1/8")	40
SMS-88-T2430B	2' 6" (30")	2' 0" (24")	3' 0 1/8" (36 1/8")	45
SMS-88-T2436B	3' 0" (36")	2' 0" (24")	3' 0 1/8" (36 1/8")	50
SMS-88-T2448B	4' 0" (48")	2' 0" (24")	3' 0 1/8" (36 1/8")	60
SMS-88-T2460B	5' 0" (60")	2' 0" (24")	3' 0 1/8" (36 1/8")	70
SMS-88-T2460B	6' 0" (72")	2' 0" (24")	3' 0 1/8" (36 1/8")	80
SMS-88-T2484B	7' 0" (84")	2' 0" (24")	3' 0 1/8" (36 1/8")	90
SMS-88-T2496B	8' 0" (96")	2' 0" (24")	3' 0 1/8" (36 1/8")	100
SMS-88-T3030B	2' 6" (30")	2' 6" (30")	3' 0 1/8" (36 1/8")	46
SMS-88-T3036B	3' 0" (36")	2' 6" (30")	3' 0 1/8" (36 1/8")	52
SMS-88-T3048B	4' 0" (48")	2' 6" (30")	3' 0 1/8" (36 1/8")	64
SMS-88-T3060B	5' 0" (60")	2' 6" (30")	3' 0 1/8" (36 1/8")	76
SMS-88-T3072B	6' 0" (72")	2' 6" (30")	3' 0 1/8" (36 1/8")	84
SMS-88-T3084B	7' 0" (84")	2' 6" (30")	3' 0 1/8" (36 1/8")	96
SMS-88-T3096B	8' 0" (96")	2' 6" (30")	3' 0 1/8" (36 1/8")	108
SMS-88-T3636B	3' 0" (36")	3' 0" (36")	3' 0 1/8" (36 1/8")	60
SMS-88-T3648B	4' 0" (48")	3' 0" (36")	3' 0 1/8" (36 1/8")	70
SMS-88-T3660B	5' 0" (60")	3' 0" (36")	3' 0 1/8" (36 1/8")	82
SMS-88-T3672B	6' 0" (72")	3' 0" (36")	3' 0 1/8" (36 1/8")	96
SMS-88-T3684B	7' 0" (84")	3' 0" (36")	3' 0 1/8" (36 1/8")	108
SMS-88-T3696B	8' 0" (96")	3' 0" (36")	3' 0 1/8" (36 1/8")	120
SMS-88-T24108B	9' 0" (108")	2' 0" (24")	3' 0 1/8" (36 1/8")	110
SMS-88-T24120B	10' 0" (120")	2' 0" (24")	3' 0 1/8" (36 1/8")	120
SMS-88-T24132B	11' 0" (132")	2' 0" (24")	3' 0 1/8" (36 1/8")	130
SMS-88-T24144B	12' 0" (144")	2' 0" (24")	3' 0 1/8" (36 1/8")	140
SMS-88-T30108B	9' 0" (108")	2' 6" (30")	3' 0 1/8" (36 1/8")	120
SMS-88-T30120B	10' 0" (120")	2' 6" (30")	3' 0 1/8" (36 1/8")	132
SMS-88-T30132B	11' 0" (132")	2' 6" (30")	3' 0 1/8" (36 1/8")	144
SMS-88-T30144B	12' 0" (144")	2' 6" (30")	3' 0 1/8" (36 1/8")	156
SMS-88-T36108B	9' 0" (108")	3' 0" (36")	3' 0 1/8" (36 1/8")	132
SMS-88-T36120B	10' 0" (120")	3' 0" (36")	3' 0 1/8" (36 1/8")	144
SMS-88-T36132B	11' 0" (132")	3' 0" (36")	3' 0 1/8" (36 1/8")	156
SMS-88-T36144B	12' 0" (144")	3' 0" (36")	3' 0 1/8" (36 1/8")	168

SMS-88-T2424B
24" W × 24" D × 36 1/8" H · Weight 40
SMS-88-T2430B
30" W × 24" D × 36 1/8" H · Weight 45
SMS-88-T2436B
36" W × 24" D × 36 1/8" H · Weight 50
SMS-88-T2448B
48" W × 24" D × 36 1/8" H · Weight 60
SMS-88-T2460B
60" W × 24" D × 36 1/8" H · Weight 70
SMS-88-T2460B
72" W × 24" D × 36 1/8" H · Weight 80
SMS-88-T2484B
84" W × 24" D × 36 1/8" H · Weight 90
SMS-88-T2496B
96" W × 24" D × 36 1/8" H · Weight 100
SMS-88-T3030B
30" W × 30" D × 36 1/8" H · Weight 46
SMS-88-T3036B
36" W × 30" D × 36 1/8" H · Weight 52
SMS-88-T3048B
48" W × 30" D × 36 1/8" H · Weight 64
SMS-88-T3060B
60" W × 30" D × 36 1/8" H · Weight 76

View all

Universal Workstation Stainless Steel Table

Product SKU

Downloads

Description

Stainless Steel Table
