Pallet Rack Beam Based Steel Shelving

Downloads

RFARevit family
PDFFinish options22 KB
PDFCut sheet301 KB
LIBMaterial library958 KB

Get Fetch to load families straight into Revit →

Family

Pricing

Rigid connections
40-foot continuous length capability
Wide variety of column sizes
Closed tube or open-section columns

Questions about this product?

Pallet Rack

The Southwest Solutions Group pallet rack line is designed to be highly flexible and adaptable with every Revit model built to reflect its real world counterpart.Standard Selective Pallet Rack is the basis for most warehouse storage systems. These can provide all varieties from light to heavy-duty, open to closed tubes, and bolted to automatic locking connections. Computerized mills ensure that tolerances on all roll-formed beams and uprights are precise and install with ease.

Specifications
Dimensions
Width	48", 60", 72", 84", 96", 108", 120", 132", 144", 288", 300"
Depth	24", 36", 42", 48"
Height	96", 120", 144", 168", 192", 240"
Beam Height	2 1/2", 3", 3 5/16", 3 9/16", 4", 4 3/16", 4 1/2", 5", 5 1/2", 6"
Beam Length	48", 60", 72", 84", 96", 108", 120", 144"
Product
Manufacturer	Southwest Solutions Group_UNA
Lead Time	Contact SSG for info
Model	PR
Primary Material	Powder coated steel
Classification
MasterFormat	10 56 29.16 – Pallet Storage Racks
UniFormat	E2020 – Moveable Furnishings
IFC	Furniture
OmniClass	23-21 11 11 15
Revit family
Includes Sustainability	Yes
Includes Pricing	Yes
ADA Compliant	No
Has MEP Connectors	No

Model	Width	Depth	Height
